| CHIPSET | INTEL B760 |
| CPU | Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors |
| | LGA 1700 |
| MEMORY | 4x DDR4, Maximum Memory Capacity 128GB |
| | Memory Support 5333(OC)/ 5200(OC)/ 5066(OC)/ 5000(OC)/ 4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) |
| | Max. overclocking frequency: |
| | • 1DPC 1R Max speed up to 5333+ MHz |
| | • 1DPC 2R Max speed up to 4800+ MHz |
| | • 2DPC 1R Max speed up to 4400+ MHz |
| | • 2DPC 2R Max speed up to 4000+ MHz |
| | |
| | Supports Dual-Channel mode |
| | Supports non-ECC, un-buffered memory |
| | Supports Intel® Extreme Memory Profile (XMP) |
| ONBOARD GRAPHICS | 2x HDMI™ |
| | Support HDMI™ 2.1, maximum resolution of 4K 60Hz* |
| | 2x DisplayPort |
| | Support DP 1.4, maximum resolution of 4K 60Hz* |
| | *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| SLOT | 2x PCI-E x16 slot |
| | 1x PCI-E x1 slot |
| | PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) |
| | PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) |
| | PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| STORAGE | 2x M.2 |
| | M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices |
| | M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices |
| | 4x SATA 6G |
| | * SATA8 will be unavailable when installing M.2 SATA SSD in the M2_2 slot. |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| USB | 2x USB 2.0 (Rear) |
| | 4x USB 2.0 (Front) |
| | 2x USB 3.2 Gen1 Type A (Rear) |
| | 4x USB 3.2 Gen1 Type A (Front) |
| | 1x USB 3.2 Gen1 Type C (Front) |
| | 2x USB 3.2 Gen2 Type A (Rear) |
| LAN | Realtek® RTL8125BG 2.5G LAN |
| AUDIO | Realtek® ALC897 Codec |
| | 7.1-Channel High Definition Audio |
| INTERNAL IO | 1x Power Connector(ATX_PWR) |
| | 2x Power Connector(CPU_PWR) |
| | 1x CPU Fan |
| | 1x Pump Fan |
| | 2x System Fan |
| | 2x Front Panel (JFP) |
| | 1x Chassis Intrusion (JCI) |
| | 1x Front Audio (JAUD) |
| | 1x Com Port (JCOM) |
| | 2x Addressable V2 RGB LED connector (JARGB_V2) |
| | 2x RGB LED connector(JRGB) |
| | 1x TPM pin header(Support TPM 2.0) |
| | 4x USB 2.0 ports |
| | 4x USB 3.2 Gen1 Type A ports |
| | 1x USB 3.2 Gen1 Type C ports |
| LED FEATURE | 4x EZ Debug LED |
| BACK PANEL PORTS | Keyboard / Mouse |
| | DisplayPort |
| | USB 3.2 Gen 1 5Gbps (Type-A) |
| | 2.5G LAN |
| | Audio Connectors |
| | USB 2.0 |
| | HDMI™ |
| | USB 3.2 Gen 2 10Gbps (Type-A) |
| | |
| OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| PCB INFO | mATX |
| | 243.84mmx243.84mm |
