Compatibility | Intel LGA1700/1200/1151/1150/1155/1156 AMD AM4 |
TDP | 180W |
Overall Dimension | 124×72×150mm (L×W×H) |
Heatsink Material | 4×Ф6mm Heatpipe(Direct Touch)+Aluminum Fin |
Weight | 810g |
Fan Dimension | 120×120×25mm |
Fan Speed | 500±200~1500±10%RPM(PWM) |
Max. Air Flow | 64.8CFM |
Max. Static Pressure | 1.87mmH2O |
Noise | 16-26.6dB(A) |
Rated Voltage | 12VDC |
Operating Voltage | 10.8～13.2VDC |
Started Voltage | 7VDC |
Rated Current | 0.28A |
Power Input | 3.36W |
Bearing Type | Hydraulic Bearing |
Connector | 4Pin PWM |
